Radar Level Gauge-HBRD704

Applicable medium: liquid, especially liquid with low dielectric constant

Application: measurement of non-ionized water, deoxygenated water and other liquids

Explosion-proof certification: Exia II C T6 Gb/Exd IIC T6 Gb

Measuring range: 6m

Frequency: 500MHz-1.8GHz

Antenna: coaxial tube antenna

Measurement accuracy: ±5mm

Process temperature: -40～130℃ (standard type) -40～250℃ (high temperature type)

Process pressure: (-0.1～4)MPa

Signal output: (4～20) mA/HART

Power supply: two-wire system (DC24V) four-wire system (DC 24V/AC 220V)

On-site display: four-digit LCD programmable

Housing: aluminum single cavity / aluminum double cavity / plastic / stainless steel single cavity

Process connection: thread/flange (optional)
